Digital concrete x-ray is the application of hard x-rays to obtain a clear image of the interior of concrete. The method is useful when you want to x-ray concrete for rebars, conduits, and post-tension cables to avoid damage when cutting or coring. By providing a precise image of exactly what structural components are within the concrete, you will be able to avoid striking any hazards during construction.
With a minimal exclusion zone, our low radiation-emitting products are becoming a new standard for concrete imaging. We are able to provide digital concrete x-ray solutions where ground-penetrating radar is not sufficient for the customer or scope of work. The X-ray can be performed on the various thicknesses of concrete depending on the scope of the project. We can capture 4″ to 14″ thick concrete in a matter of seconds providing improved workflow compared to conventional RT.


PiX Software, with its “SINGLE CLICK” process makes acquiring images easy, just launch the software and Pacific DR & x-ray are auto-connected. Press “Capture” & the image is acquired within a few seconds & wirelessly transferred to a laptop or PC for immediate review and analysis.

Image library

Lower Radiation (No Gamma)

Excellent Customer Support

Plug & Play Solution

Single Click Image Capture

ConcreteX Imaging Module

Full-field AED & Trigger Mode

Rugged Rhino protective Armor

Low Power Consumption

High Sensitivity Mode

Suite Of NDT Tools

Concrete Inspection Services

Bridge Inspection

Construction Projects

Tunnel Inspection

Immediate Image capture & review (ready in seconds)

Small exclusion zone compared to conventional RT

Cloud Image Archiving and sharing

Automatic Report Generator

Immediate return on Investment (contact us to learn more)
PI Software Features
Zoom, Pan, Rotate, Flip | Image Storage, Import/Export, Diconde |
Text, Shapes, Distances, Areas | Line Profile, Duplex Wire |
Invert, Window/Level, Histogram | Pipe wall Thickness Measurement |
Crop, Mask, ROI, Overlay | ROI Statistics, SNR, CNR |
Best fit, 1:1 Display, Split Display | Image Processing, Flitters, Embossing, False Colors |
Undo, Redo, Reset, Presentation State | Pipeline, Trigger, Plugins |
Configurable UI, Multi-Language | Reporting |
Info for Part and Study, Overlay | User Loggins, Roles |
Pacific NDT Concrete Inspection System
